Quick 861DW SMD Rework Station


₹ 19998 ₹ 40000 50% off


* With CH1, CH2, and CH3 three working channels, and each channel can be set air volume, the temperature.

* Product model: 861DW

* Power consumption: 1000W

* Working voltage: AC 220V

* Temperature range: 100°C-500°C/212°F~932°F

* Range of air volume: 1-120 Class

* Airflow: 50L/min (Max)

Out of Stock

Description

Quick 861DW SMD Rework Station

The Quick 861DW is widely considered the industry standard for high-end SMD rework. Renowned for its precision, thermal stability, and high-volume airflow, it is a staple for professional technicians performing complex motherboard repairs and micro-soldering.

Below is the comprehensive technical breakdown and product description.

Quick 861DW Professional Hot Air Rework Station

Feature Category Technical Specifications & Details
Model Name Quick 861DW (Lead-Free Professional Digital Rework Station)
Power Consumption 1000W (High-efficiency heating element)
Input Voltage Available in 110V (US) or 220V (EU/Global) versions
Temperature Range 100°C to 500°C (212°F to 932°F)
Airflow Volume 1 to 120 L/min (Adjustable via digital control)
Heating Component High-quality ceramic heating core
Pump Type Brushless whirlpool fan (Low noise, high durability)
Display Digital LCD Screen (Backlit for clear visibility)
Memory Channels 3 Channels (CH1, CH2, CH3) for custom presets
Auto-Sleep Mode Magnetic induction switch in handle for instant cooling/sleep
Cooling Function Automatic large-volume cooling system to protect heating element
Dimensions Approx. 188 x 245 x 135 mm
Weight Approx. 3.65 kg (Heavy-duty chassis for stability)

Core Functionality & Key Features

  • Precision Control: The closed-loop sensor and microcomputer-controlled temperature system ensure that the heat remains consistent regardless of the airflow volume. This prevents "thermal shock" to sensitive IC components.

  • Three-Channel Presets: Technicians can store three distinct "profiles." For example:

    • CH1: Low heat/Low air for sensitive plastic connectors.

    • CH2: Medium heat for standard SMD components.

    • CH3: High heat/High air for heavy ground planes or lead-free solder removal.

  • Brushless Vortex Fan: Unlike diaphragm pumps used in older stations, the 861DW utilizes a brushless whirlpool motor. This provides a smoother, more "fluid" air delivery that is significantly quieter during operation.

  • Safety & Longevity: The handle is equipped with a magnetic sensor. As soon as the handle is placed back into the stand, the station automatically kicks into high-airflow cooling mode until the temperature drops below 100°C, then enters sleep mode. This drastically extends the lifespan of the heating element.

  • Password Protection: Includes a system lock feature to prevent unauthorized or accidental changes to the temperature and airflow settings.

Quick 861DW SMD Rework Station

Quick 861DW SMD Rework Station

Quick 861DW SMD Rework Station

Quick 861DW SMD Rework Station
