Mechanic D75t Pro Master Edition Microscope With 0.5X Lence


₹ 18499 ₹ 30000 38% off


  • * Product Name: Industrial grade trinocular stereo microscope
  • * Product Model: D75T-PRO MASTER EDITION
  • * Magnification: Standard 0.7-4.5X(Optional 2.1X-180X)
  • * Eyepiece: 0.5X CTV HD electron microscope
  • * Objective Len: 0.7X-50X
  • * Eyepiece: WF10X25 High Eyepiece
  • * Observation Head: Binocular observation head 45°tilt, eyepiece pupil spacing adjustment range 54-76mm; Binocular visual acuity adjustable
  • * Working distance: The effective distance is 100mm, and the purchase of an auxiliary objective lens can be extended to 30-287mm
  • * Focusing bracket: Adjustable elasticity of focusing handwheel, lifting range 50mm
  • * Base Size: 195*256*20mm
  • * LED light source: High brightness cold white light source, can be adjusted freely
  • * Applicable Fields: Teaching Demonstration, PCB electronics signal mobile phone processing and repair Component Assembly, electronic component detection
Out of Stock

Stay tuned, It is coming soon!!
Description

Mechanic D75t Pro Master Edition Microscope With 0.5X Lence

The Mechanic D75T Pro Master Edition is a flagship-grade trinocular stereo microscope engineered specifically for professional electronics repair, micro-soldering, and forensic inspection. This "Master Edition" is distinguished by its enhanced optical clarity and a large-diameter eyepiece system that reduces eye fatigue during long working hours.

When paired with the 0.5X Barlow Lens, the microscope significantly increases its working distance, allowing ample room for soldering irons, hot air tweezers, and rework stations under the lens.

Product Specifications: Mechanic D75T Pro Master Edition

Feature Detailed Specification
Model D75T Pro (Master Edition)
Head Type 45° Inclined, 360° Swiveling Trinocular Head
Optical System Greenough Stereoscopic System
Magnification Range 7X – 45X (Standard)
Magnification with 0.5X Lens 3.5X – 22.5X
Zoom Ratio 1:6.4
Eyepieces WF10X/22mm (High Eyepoint, Wide Field)
Working Distance (Standard) 100mm
Working Distance (with 0.5X) Approximately 165mm – 185mm
Interpupillary Distance 54mm – 76mm
Diopter Adjustment ±5dp on both ocular tubes
Trinocular Port 0.5X CTV Interface (Simul-focal supported)
Base Type B11 Large Integrated Aluminum Alloy Base
Lighting Adjustable LED Ring Light (typically 56-72 LEDs)

Core Performance Features

1. Simul-Focal Optical System

Unlike standard trinocular microscopes where the eyepieces go dark when the camera is engaged, the D75T Pro features a simul-focal system. This allows the technician to view the component through the eyepieces while simultaneously streaming or recording high-definition video through the trinocular port.

2. The 0.5X Barlow Lens Advantage

The inclusion of the 0.5X auxiliary objective lens is a game-changer for motherboard repair:

  • Expanded Working Space: It nearly doubles the vertical space between the lens and the motherboard, preventing the microscope from being hit by hot air nozzles.

  • Wider Field of View (FOV): It allows the user to see a larger portion of the PCB at once, which is critical for identifying trace paths or searching for scorched components.

3. Master Edition Optics

The "Master Edition" utilizes upgraded high-refractive-index glass with multi-layer anti-reflective coatings. This results in:

  • True Color Rendering: Critical for identifying resistor color codes and subtle solder joint oxidization.

  • High Sharpness: Edge-to-edge clarity without the "fisheye" distortion found in entry-level optics.



Comparison: Standard 75T vs. D75T Pro Master Edition

Feature Standard 75T Series D75T Pro Master Edition
Eyepiece Diameter 20mm 22mm (Super Wide Field)
Coating Standard Blue/Green Advanced Multi-layer HD Coating
Base Material Medium Plastic/Alloy Heavy-Duty Oversized Alloy Base
Focusing Rack Basic Friction Gear Precision Metal Gear with Tension Control
Eye Relief Standard Long Eye Relief (Comfortable with glasses)

Mechanic D75t Pro Master Edition Microscope With 0.5X Lence



Mechanic D75t Pro Master Edition Microscope With 0.5X Lence
