Description

Relife Rl-936wg Battery Spot Welding Machine

Features:
Adjustable full-parameter color screen/Double pulse spot welding/Three levels of pre-selection
Chinese/English HD color screen/Adjustable parameters, LCD-IPS display
Three levels of pre-selection, preset three groups of low, medium, and high convenient pre-selected spot welding parameters
Double pulse spot welding, and multi-stage pulse spot welding are stronger
Red copper replaceable soldering tip, copper nib, more conductive, 650A high magnification output, large capacity battery output, long battery life
Excellent product design + sufficient high-quality materials, efficient operation, continuous welding without waiting
Double pen welding, welding pen + electrode two welding methods, multi-stage pulse spot welding is stronger and can be adapted to welding in multiple scenarios
You can check the voltage, current voltage, and temperature of the inspection machine, and you can preset three levels: preheating, pulse, and connection points
The tip of the spot welding pen is replaceable. If the tip is worn out, it can be replaced to reduce the cost of later use
Distinguish the switch/select key to optimize the output power adjustment, making the application more convenient and faster
High-temperature resistant silicone material, more stable maintenance point operation
Built-in rechargeable lithium battery, longer battery life, USB charging plug, convenient and fast

Specifications:
Brand: RELIFE
Product name: High power battery spot welding machine
Model: RL-936WG
Net weight: ≈320g
Soldering pen size: ≈420mm
Charging cable length: ≈1020mm
LCD size: 2.0 inches
Package Size: 210*160*50mm
Design current: 650A(Max)
Input interface: Type-C charger
Input parameters: 5V/3A(Max)
The output voltage: 4.2V(Max)
Battery: Lithium polymer battery
Operating temperature: -10~60?
Charging temperature: 0~60?

Package includes:
1 x Host
1 x Negative Electrode Welding Pen
1 x Positive Electrode Welding Pen
2 x Nickel Sheet
1 x Charging Cable
