JTX FS-16 IP-03 A10-IP7/PLUS 012 Stencil


₹ 119 ₹ 300 60% off


* Type: UV Stencil Oil designed for stencil applications.

* Color: Green, providing a vibrant finish for stenciled designs.

* UV Protection: Offers excellent UV resistance, preventing designs from fading under sunlight.

* Viscosity: Medium viscosity, ideal for smooth stencil application without running or clogging.

* Formulation: Non-toxic, environmentally friendly formula for safe use.

* Drying Time: Quick-drying formula that ensures minimal wait time between applications.

* Surface Compatibility: Suitable for a wide range of surfaces including wood, metal, plastic, fabric, and more.

* Water Resistance: Once dry, the oil becomes water-resistant, ensuring long-lasting durability.

* Usage Method: Can be applied with a stencil brush, sponge, or spray, depending on the desired effect.

1

Description

JTX FS-16 IP-03 A10-IP7/PLUS 012 Stencil

  • Stencil Purpose: Stencils are used for the precise application of solder paste to solder pads on a PCB. This solder paste serves as a temporary adhesive that holds surface-mount components (SMDs) in place during the soldering process.
  • Reballing: Stencils are also commonly used in reballing processes, which involve removing and then re-soldering a component, such as a BGA (Ball Grid Array) chip. The stencil helps apply solder balls to the component's pads with precision.
  • Compatible Devices: The stencil is likely designed for use with specific models. Each stencil is typically designed to match the component layout of a particular device or series.
  • Aperture Design: The stencil features a pattern of tiny apertures (holes) that align with the solder pads on the PCB or component. When solder paste is applied over the stencil and pushed through these apertures, it deposits a controlled amount of solder onto the pads.
  • Stencil Material: Stencils are commonly made from stainless steel or other durable materials to withstand repeated use and exposure to high-temperature soldering processes.

JTX FS-16 IP-03 A10-IP7/PLUS 012 Stencil
